UTP1310S UTP1310 DC stabilized power supply

UTP1310S DC stabilized power supply Current 0~10A Voltage 0~30V, resolution 10mV, 1mA; Four-digit power display LED four-digit voltage and current display, 3 sets of data storage, support one-key recall, with key lock function to avoid misoperation; Voltage, overcurrent, overtemperature, with short circuit, overload, reverse polarity and other functions. Because the output voltage time of the chip test fixture is only 15 seconds, when we repair the voltage of the hash board, 15 seconds is not enough, so the UTP1310S DC stabilized power supply can perfectly solve this problem. In the repair of the hash board failure, the stabilized PSU can replace the output voltage of the test fixture, and the time of the output voltage is not limited, which is convenient for us to test the powering unit of the hash board and improve the repair efficiency.

Note: UTP1310S has been discontinued and UTP1310 will be sent by default.

Note: When using the adjustable voltage power supply to test the hash board, you need to use a fan to dissipate the heat. If the heat dissipation is not good, the current of the adjustable voltage power supply will increase, and the hash board will become hot and cause damage.

Parameters：

Model: UTP1310

Rated output voltage / current: 0~32V/0~10A

Output power: 320W

Load regulation rate: voltage: ≤0.1%+5mV; current: ≤0.2%+3mA

Power regulation rate: voltage: ≤0.01%+5mV; current: ≤0.2%+3mA

Setting resolution: voltage: 10mV; current: 1mA

Readback resolution: Voltage: 10mV; Current: 1mA

Setting accuracy: voltage: ≤0.1%+1 digits; current: ≤0.2%+3mA

Ripple: Voltage: ≤10mVrms; Current: ≤5mArms

OCP (over current protection): 0~10A±0.2%F

OVP (over voltage protection): 0~32V±0.2%FS

Maximum current: 10.0A±0.2%

Display type: LCD digital tube display

Power supply voltage: AC 110/220V+10%

Maximum voltage: 32V ±0.2%

Size (W*H*D): 80mm*150mm*230mm

Weight: 2.5kg
