Telegram : @zeusmining_presales0402 SMD Ceramic Capacitor In electronic circuits, chip capacitors are currently very common chip electronic components. It has the functions of filtering, energy storage, and coupling. If the chip capacitor of the hash board, control board, or power supply is missing or the wrong capacity is used, it may cause the circuit to be abnormal. When replacing, it is necessary to replace capacitors with the same size, the same or higher withstand voltage, and the same or higher capacity.
At present, 0402 chip capacitors are the most common and cost-effective size. The minimum capacitance can be 0.05PF, and the maximum capacitance can be 22UF. Those larger than 22UF can only be 0603 and above because the capacity of the capacitor is proportional to the size of the capacitor.
0402 chip capacitors cover almost all electronic product applications, such as crypto miners, mobile phones, smart homes, automotive electronics, industrial automation, medical equipment, etc.
0402 Capacitor 0.1UF 1UF suit for Antminer, Whatsmienr, Avalon, Innosilicon, Ebit, etc.
The most common parameters of 0402 chip capacitors are as follows:
0402 5PF COG ±0.25PF 50V
0402 10PF COG 5% 50V
0402 22PF COG 5% 50V
0402 27PF COG 5% 50V
0402 33PF COG 5% 50V
0402 68PF COG 5% 50V
0402 220PF COG 5% 50V
0402 220PF X7R 10% 50V
0402 330PF COG 5% 50V
0402 330PF X7R 5% 50V
0402 680PF X7R 10% 50V
0402 1NF/1000PF X7R 10% 50V
0402 2.2NF X7R 10% 50V
0402 2.7NF X7R 10% 50V
0402 3.3NF X7R 10% 50V
0402 4.7NF X7R 10% 50V
0402 10NF X7R 10% 50V
0402 22NF X7R 10% 50V
0402 27NF X7R 10% 50V
0402 33NF X7R 10% 50V
0402 47NF X7R 10% 50V
0402 100NF/0.1UF X7R 10% 16V
0402 100NF/0.1UF X7R 10% 25V
0402 100NF/0.1UF X7R 10% 50V
0402 220NF/0.22UF X7R 10% 16V
0402 470NF/0.47UF X5R 20% 10V
0402 1UF/105KX5R 10% 6.3V
0402 1UF/105K X5R 10% 10V
0402 1UF/105K X5R 10% 16V
0402 1UF/105K X5R 10% 25V
Due to there being many types of chip capacitors, if you need more models and parameters, please contact the sales manager for details.
SMD component sizes imperial and metric:
Imperial size code | Dimension L x W inch x inch | Metric size code | Dimension L x W mm x mm |
0201 | 0.02 x 0.01 | 0603 | 0.6 x 0.3 |
0402 | 0.04 x 0.02 | 1005 | 1.0 x 0.5 |
0603 | 0.06 x 0.03 | 1608 | 1.5 x 0.8 |
0805 | 0.08 x 0.05 | 2012 | 2.0 x 1.3 |
1206 | 0.12 x 0.06 | 3216 | 3.2 x 1.6 |
1210 | 0.125 x 0.1 | 3225 | 3.2 x 2.5 |
1812 | 0.125 x 0.18 | 4532 | 3.2 x 4.6 |
2010 | 0.20 x 0.10 | 5025 | 5.0 x 2.5 |
2512 | 0.25 x 0.125 | 6332 | 6.3 x 3.2 |
