Whatsminer M33S++

Hydro cooling miner MicroBT Whatsminer M33S++

Location: HK

Stock: 170 units

Whatsminer M33S++ uses SHA-256 algorithm to mine BTC, the maximum hash rate is 242Th/s, and the power consumption is 6820W.

Specification:

Hash rate: 220T ±10%

Power Ratio: 31J/T ± 5%

PSU: AC380V, 3W+ ground, input 10kw

Size: 86mm * 482.6mm * 650mm

Net weight: 27.5kg

Coolant demand per machine: About 1L

Internet Connections: Ethernet

Humidity:

Working humidity: 5% RH ~ 85% RH (non-condensing)

Storage humidity: 5% RH ~ 95% RH (non-condensing)

Long-term storage humidity: 30% RH ~ 69% RH (no condensation)

Liquid temperature:

Working temperature (inlet): 20℃ ~ 50℃ @ normal mode 20℃ ~ 40℃ @ high performance mode;

Inlet temperature control accuracy ± 2℃;

Storage and transportation temperature: -40 ~ 70℃.

Note: please empty the liquid in the equipment during storage and transportation. If it is not emptied, ensure that the equipment is above the freezing point of the liquid.

Liquid flow:

Limited Data: ≥10L/min

Flow control accuracy ± 10%

Remarks: 10L/min corresponds to the temperature difference between the inlet and outlet water close to 10℃ @ normal mode, 14℃ @ high performance mode

Liquid pressure: ≤350kpa

Note: when the temperature of the coolant rises after the miner is turned on the pressure will rise. when the pressure is more than 300kpa, the water-cooled plate will be deformed and cause the risk of coolant leakage.

Liquid medium: First-level deionized water: meet the requirements of the national standard GB/T 6682-2008 first-level deionized water

Notice:

1) If the water conductivity is ≥100us/cm, the medium must be replaced;

2) The water conductivity is less than 5us/cm when the system is running for the first time.

Liquid PH: Control range: 6 ~ 8

Remarks: The above liquid temperature and flow parameters are based on deionized water as the liquid medium. If the liquid medium uses antifreeze, the liquid temperature and flow parameters need to be calculated separately.
