Bitmain Antminer S17 pro

Bitmain Antminer S17 Pro (53T-59T) model, using SHA-256 algorithm, the maximum hash rate is 59Th/s. Antminer S17 Pro miner continues the all-in-one design and continues to optimize the overall structure. The fuselage adopts a double-tube fan design, the air distance is shortened by half, the temperature difference between the air inlet and outlet of the miner is reduced, and the performance of the machine is greatly improved. In addition, the S17 Pro uses a new high-power power supply; the power supply model is APW9, which adopts a dual-channel design, the maximum output voltage is 14.5V-21V 170A, and the maximum power is 3600W. (This value is under the 220V voltage input environment), which can effectively ensure the stability of the miner operation.

In terms of heat dissipation design, the Antminer S17 Pro uses a standard air-cooled heat dissipation module and two 12V industrial-grade fans on the front and rear of the fuselage from a DC air duct. The fan adopts an adjustable speed design, which can intelligently adjust the speed according to the temperature of the core to further meet the cooling needs of the machine. The top of the miner is equipped with protective devices to protect the cables and internal components. In order to effectively protect the internal components of the miner  and reduce maintenance costs in the later period, the S17 Pro adopts a new fuselage structure and is equipped with protective devices on the top of the miner, making the miner run more safely.

Feature:

Hash rate: 53T - 59T

Operating temperature: 0 to 40 degrees

Network connection: RJ45 Ethernet switch 10/100M

Default frequency: set automatically

Chip name: Antminer BM1397AD

Number of chips: 3 hash boards total 144

Noise level: 82 decibels

Fans: 4

Voltage: 12V

Interface: Ethernet

Temperature: 5 - 45 °C

Humidity: 5 - 95 %
