Bitmain Antminer APW3++ PSU

Brand new Bitmain Antminer APW3++ 1200-1600W 110-240V power supply unit PSU for ASIC miner Antminer S7 S9 S9I S9J S9K S9SE T9

The recommended input voltage of Bitmain APW3++ power supply is 220V. Any voltage over 380V will damage the PSU. All power supplies are fully tested before shipment.

Feature:

1. The input voltage range is 100-240 V;

2. The power supply can be switched remotely (set by yourself);

3. Active power factor correction, PF> 0.99 (full load);

4. The highest efficiency reaches 93.5%;

5. Short circuit, overload, over temperature protection;

6. The speed of the cooling fan will automatically adjust with temperature fluctuations.

Technical index:

Output

DC voltage: 12.15 V

Rated current (220V input): 133 A

Rated current (110V input): 100 A

Rated power (220V input): 1600 W

Rated power (110V input): 1200 W

Interface type: 5-pair 6-pin PCIE connector (10 connectors)

Noise level <43 dB

Input Value

Voltage range: 100-240 V A / C

Starting voltage: 95-105 V A / C

Frequency range: 47-63 Hz

Surroundings

Working temperature: -20°C-50°C

Working humidity: 20% - 90% relative humidity (no condensation)

Structure: size 220x108x62 mm

Cooling fan: forced air cooling
