| Unit Price: | $ 2 |
WhatsApp : +8618623251355
Telegram : @zeusmining_presalesMOS chip RS1E320GN is suitable for L3+ hash board MOS chip replacement and repair. After the MOS chip is damaged, there is no voltage or abnormal voltage on the whole board. Usually when 0 ASIC is prompted (the number of chips reported by the fixture test is 0), first check the voltage in the voltage domain, if it is not normal, it is likely to be a MOS failure.
Features:
Low resistance;
High power package (HSOP8);
Lead-free, RoHS compliant, halogen free;
100% Rg and UIS tested;
Junction-to-ambient thermal resistance: 41.7 °C/W, thermal resistance: 3.6 °CW.
Parameters:
RDS(on) (max): 1.9mΩ
lD: ±32A
Power: 3.0W
Drain-source voltage(VDSS ): 30V
Continuous drain current: T. =25℃±80A(LD*1)T. =25℃ ±32A (LD)
Pulsed drain current: ±128A
Gate-source voltage: ±20V
Avalanche energy single pulse: 77.7mJ
Avalanche current: 32A
Power consumption: 34.6 W(PD*1) 3.0W(PD*4)
Junction temperature: 150℃
Storage temperature range: -55 to +150°C
