ISL99227B
ISL99227B
Ratings:
( 527 Reviews )
ISL99227B
Function: Antminer Z11 Z9 hash board smart power stage module.
Unit Price: $ 9.5
MOQ: 10    Unit Weight: 0.001 KG    Availability: In Stock
- +
+ Add to cart
If you dont know how to place an order please check our FAQs

Tech support and pre-sale:
WhatsApp : +8618623251355
Telegram : @zeusmining_presales
Download the BOM for one-stop delivery
Product description:

ISL99227BFRZ-T Smart Power Stage (SPS) Module The ISL99227B is Smart Power Stage (SPS) compatible with ISL68xxx / ISL69xxx Digital Multiphase (DMP) controllers and phase doubler (ISL6617A), respectively. The ISL99227B has integrated high accuracy current and temperature monitors that can be fed back to the controller and doubler to complete a multiphase DC/DC system. They simplify design and increase performance by eliminating the DCR sensing network and associated thermal compensation. Light-load efficiency is supported through a dedicated LFET control pin.

The ISL99227B features 5.0V compatible tri-state PWM input. The ISL99227B also improves system performance and reliability with integrated fault protection of UVLO, over-temperature, and overcurrent. An open-drain fault reporting pin simplifies the handshake between SPS and Intersil controllers and can be used to disable the controller during start-up and fault conditions.

ISL99227B power management chip

Specification:

Part number: ISL99227BFRZ-T

Surface marking: 27B

Operating temperature range: -40 to +125°C

Rated current: 60A

PWM input: 5.0V

Package: 32 Ld 5*5 PQFN double cooling

Applications:

High frequency and high efficiency VRM and VRD

Core, graphic, and memory regulators for microprocessors

High density VR for server, networking, and cloud computing

POL DC/DC converters and video gaming consoles
